Kompletní specifikace:

Video Stream Input Support 1 - HEVC & H.264 MPEG-H HEVC (ISO/IEC 23008-2)

• Profile/Level - Profile/Level: up to Main422 10@L4.1 High Tier
• Color sampling / Bit-depth: up to 4:2:2 / 10 bits
• Bit Rate: up to 50Mbps
• Frame Rate: 1-60 fps.
• Input Resolutions: from CIF up to 1920x1080

Video Stream Input Support 2 - MPEG-4 AVC/H.264 (ISO\IEC 14496-10 MPEG-4 AVC Rec. ITU-T H.264)

• Profile/Level: up to Hi10@L4.2
• Color sampling / Bit-depth: up to 4:2:2 / 10 bits
• Bit Rate: up to 100Mbps
• Frame Rate: 1-60 fps.
• Input Resolutions: from CIF up to 1920x1080

Audio Stream Input Support - MPEG-4 AAC-LC (ISO/IEC 14496-3) Up to x2 stereo channel

• Audio Sample Rate: 48kHz
• Audio Bit rate: 16-192kbs

Output Resolutions / Frame Rates

• 1920x1080p @ 60, 59.94, 50, 30, 29.97, 25, 24, 23.976
• 1920x1080i @ 60, 59.94, 50 Hz
• 1280x720p @ 60, 59.94, 50, 30, 29.97, 25
• 720x480i @ 59.94 Hz (NTSC)
• 720x576i @ 50 Hz (PAL)

Network Protocols

• UDP TS - Yes
• RTP TS - Yes
• RTP ES - Yes
• ZIXI - Yes, Error-Correction (HEVC and H.264) – Zixi P2P and Broadcaster modes
• RTP TS ProMPEG - Yes, with ProMPEG Forward Error Correction

Network Interfaces

• Ethernet Ports - 2x Gigabit Ethernet ports for management and/or streaming
• Other Ports - VB-ASI Input and Output (available in future release)

Video Outputs

• HDSDI - Yes, 2 x 3G/HD-SDI/SD-SDI (SMPTE 259, SMPTE 274M, SMPTE 296M, SMPTE 424M)
• HDMI - Yes, 1 x V 2.0
• Composite - Yes

Audio Outputs

• Embedded SDI - Yes, SDI x 2 with Embedded audio (PCM support)
• Embedded HDMI - Yes, HDMI Embedded audio (PCM support)
• Digital - Yes, AES3 Digital Audio (BNC Female)
• Analog unbalanced - Yes, 1 x Analog unbalanced stereo audio, AC-coupled (RCA Female)
• Analog Balanced - Yes, 1 x Balanced analog stereo audio (XLR Male)

Security

• Real-time AES decryption for video, audio and metadata

Management

• Secure Web based remote management interface (HTTPS)
• Dashboard with detected channel characteristics description and active outputs
• Zixi streaming statistics for easier configuration and enhanced Quality of Service
• Status LED's for power, network activity, error and streaming indications
• Autostart mode recovers saved configuration after power cycle
• Remote firmware and software upgrade capability via browser and command line·
• Hardware push-button for restoring unit to factory settings
• Recovery or initialization of Ethernet settings over USB thumb drive
